LEGEND 151 - 15" GUITAR SPEAKER
|
|
|
LEGEND 151 - 15" GUITAR SPEAKER |
|
THE EMINENCE LEGEND 151 HAS A NICE WARM BALANCED SOUND THAT IS SWEET SOUNDING! |
|
|
|
Item Price: $144.99 Free UPS Ground Shipping in the U.S. |
|
SPEAKER
MODEL |
LEGEND
151 |
|
SPECIFICATIONS |
|
|
Nominal
Basket Diameter |
15.1"
/ 384mm |
|
Impedance |
8
ohms
|
|
RMS
Power Rating |
150
Watts |
|
Usable
Frequency Response |
60Hz -
4kHz |
|
Voice
Coil Diameter |
2"
/ 50.8mm |
|
Sensitivity
(1W/1m) |
102.2dB |
|
Magnet
Weight |
59
oz. |
| Net Weight | 12.1lbs. / 5.5 kg. |
| Shipping Weight | 14.1lbs. / 6.4 kg. |
|
MOUNTING INFORMATION |
|
|
|
15.15" / 384.8mm |
| Bolt Circle Diameter |
|
| Baffle Cutout Diameter | 13.77" / 349.6mm |
| No. Of Mounting Holes | 8 |
| Mounting Hole Diameter | 0.25" / 6.4mm |
| Overall Depth | 6.1" / 155mm |
|
MATERIALS |
|
| Basket | Pressed Steel |
| Voice Coil | Polyimide Coated Copper |
| Dust Cap | Zurette |
| Cone | Paper |
| Surround | Paper Cone Edge |
| Magnet | Ferrite |
|
THIELE-SMALL PARAMETERS |
|
| Resonant Frequency (fs) | 82 Hz |
| Impedance (Re) | 7.16 ohms |
| Coil Inductance (Le) | 0.86mH |
| Electromagnetic Q (Qes) | 1.02 |
| Mechanical Q (Qms) | 10.12 |
| Total Q (Qts) | .93 |
| Compliance Equivalent Vol. (Vas) | 65.4 Liters / 2.31cu.ft. |
| Voice Coil Overhang (Xmax) | 0.8mm |
| Surface area of Cone (Sd) | .08237m2 |
| BL Product (BL) | 14.1 T-M |
| Displacement Volume (Vd) | 65 cc |
| Diaphragm Mass Inc. Airload (Mms) | 55 grams |
| Mechanical Compliance (Cms) | .07mm/N |
| Mechanical Resistance (RMS) | 2.8N*sec/M |
| Efficiency Bandwidth Product (EBP) | 80 |
|
|
|
