• THE EMINENCE WHEELHOUSE 150 IS A 15" GUITAR SPEAKER THAT HANDLES 150 WATS RMS
• FEATURES A HEMP CONE, LIGHTWEIGHT NEODYMIUM MAGNET & HIGH SENSITIVITY OF 101.5DB SPL
• DESIGNED TO GIVE A SMOOTH WARM TONE THROUGH ITS' ENTIRE FREQUENCY RANGE FROM 60HZ TO 3.5KHZ
• WORKS WELL FOR COUNTRY, FUSION & BLUES
• WELL SUITED FOR APPLICATIONS IN OPEN OR CLOSED BACK CABINETS
• MADE BY HAND IN THE USA
• AVAILABLE IN 8 OHMS ONLY

THIS EMINENCE WHEELOUSESE 200 IS A 15 INCH GUITAR SPEAKER DELIVERS A WARM SMOOTH SOUND & HANDLES 200 WATTS RMS!
Free UPS Ground Shipping in the U.S.	No Longer Available
SPEAKER MODEL	WHEELHOUSE 200
SPECIFICATIONS
Nominal Basket Diameter	15" / 381mm
Impedance	8 ohms
RMS Power Rating	200 Watts
Usable Frequency Response	60Hz-3.5kHz
Voice Coil Diameter	2.5" / 64mm
Sensitivity (1W/1m)	101.5dB
Magnet Weight	11 oz.
MOUNTING INFORMATION
Overall Diameter	15.16" / 385.1mm
Bolt Circle Diameter	14.56" / 369.8mm
Baffle Cutout Diameter	13.87" / 352.3mm
No. Of Mounting Holes	8
Mounting Hole Diameter	0.25" / 6.35mm
Overall Depth	5.63" / 142.9mm
Net Weight	8.2lbs. / 3.7 kg.
Shipping Weight	10.4lbs. / 4.7 kg.
MATERIALS
Basket	Pressed Steel
Voice Coil	Edgewound Aluminum
Coil Former Material	Polyimide
Dust Cap	Treated Paper
Cone	Hemp
Core Details	Vented
Surround	Paper
Magnet	Neodymium
THIELE-SMALL PARAMETERS
Resonant Frequency (fs)	51 Hz
Impedance (Re)	7.49 ohms
Coil Inductance (Le)	0.46mH
Electromagnetic Q (Qes)	0.46
Mechanical Q (Qms)	16.85
Total Q (Qts)	.44
Compliance Equiv. Vol. (Vas)	182.7 Liters / 6.45 cu. ft.
BL Product (BL)	15.58 T-M
Voice Coil Overhang (Xmax)	2.22mm
Diaphragm Mass (Mms)	47 Grams
Surface Area of Cone (Sd)	.07917m2
FREQUENCY RESPONSE GRAPH
