APT-30 - COMPACT SUPERTWEETER
|
|
|
APT-30 - COMPACT SUPERTWEETER |
|
THE EMINENCE APT-30 IS A VERY SMALL COMPACT SUPERTWEETER FOR TIGHT SPACES! |
|
|
|
Item Price: $29.99 |
| MODEL | APT-30 |
|
SPECIFICATIONS |
|
|
Dispersion |
80° Conical |
|
RMS
Power Rating |
10 Watts @ 3.5kHz (18dB/octave) |
|
Impedance |
8
ohms |
| Sensitivity | 93.4dB SPL |
|
Resonance |
2.2KHz |
|
Usable
Frequency Range |
3.5kHz
- 20kHz |
|
Recommended
Crossover |
3.5kHz
|
|
MATERIALS |
|
| Voice Coil Former | Aluminum |
| Diaphragm | Mylar |
| Horn | ABS |
|
Magnet |
Ferrite |
|
DIMENSIONS |
|
| Overall Width | 2.61" / 66.2mm |
|
Overall
Height |
2.61" / 66.2mm |
| Overall Depth | 1.875" / 45.2mm |
|
Cut-O |
2.31" / 59mm |
| Net Weight | 0.4lbs. / .18 kg. |
|
FREQUENCY RESPONSE |
|
|
|
|
